DIN 439 M4 Thin Hex Nut
In stock in 14 material, grade and finish combinations.
Dimensions at M4
mm · DIN 439 · 1987-10 · withdrawn| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M4 | – | – |
| P | Thread pitch | 0.7 | – | – |
| s | Width across flats | – | – | 7 |
| e | Width across corners | – | 7.66 | – |
| m | Nut height | 2.2 | – | – |
| Approx. mass | 0.57 | – | – |
- Approx. weight
- ≈ 0.57 kg per 1 000 pieces · Bare steel, before coating and packing.1754 pieces per kg
