DIN 439 M5 Thin Hex Nut
In stock in 14 material, grade and finish combinations.
Dimensions at M5
mm · DIN 439 · 1987-10 · withdrawn| Dimension | Nominal | Min | Max | ISO 4035 | |
|---|---|---|---|---|---|
| d | Thread size | M5 | – | – | M5 |
| P | Thread pitch | 0.8 | – | – | 0.8 |
| s | Width across flats | – | – | 8 | 8 |
| e | Width across corners | – | 8.79 | – | 8.79 |
| m | Nut height | 2.7 | – | – | 2.7 |
| Approx. mass | 0.83 | – | – | — |
- ISO 4035
- Values in bold differ from DIN 439.
- Approx. weight
- ≈ 0.83 kg per 1 000 pieces · Bare steel, before coating and packing.1205 pieces per kg
