DIN 938 M24 x 80 Metal End 1d Double End Stud
In stock in 10 material, grade and finish combinations.
Dimensions at M24 x 80
mm · DIN 938 · dimensions from 2012-12 · current edition 2025-08| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M24 | – | – |
| P | Thread pitch | 3 | – | – |
| l | Length | 80 | – | – |
| bm | Metal end thread length | 24 | – | – |
| b | Thread length | 54 | – | – |
| ds | Stud shank diameter | – | 23.67 | 24 |
| x1 | Thread runout x1 | 7.5 | – | – |
| x2 | Thread runout x2 | 3.8 | – | – |
- Length excl. metal end
- 80 mm · 79.4–80.6 mm to DIN 938
- Approx. weight
- ≈ 323.00 kg per 1 000 pieces · Bare steel, before coating and packing.3.1 pieces per kg
Holes for this thread
ISO 273 · ISO 2306Clearance hole · fine25 mm
Clearance hole · medium26 mm
Clearance hole · coarse28 mm
Tap drill21 mm
