DIN 6923 M20 Hex Flange Nut
In stock in 16 material, grade and finish combinations.
Dimensions at M20
mm · DIN 6923 · 1983-06 · withdrawn| Dimension | Nominal | Min | Max | ISO 4161 | |
|---|---|---|---|---|---|
| d | Thread size | M20 | – | – | M20 |
| P | Thread pitch | 2.5 | – | – | 2.5 |
| s | Width across flats | – | – | 30 | 30 |
| e | Width across corners | – | 32.95 | – | 32.95 |
| m | Nut height | 20 | – | – | 20 |
| dc | Flange diameter | 42.8 | – | – | 42.8 |
- ISO 4161
- Values in bold differ from DIN 6923.
- Approx. weight
- ≈ 80.56 kg per 1 000 pieces · Bare steel, before coating and packing.12.4 pieces per kg
