DIN 6796 M12 Conical Spring Washer
In stock in 4 material, grade and finish combinations.
Dimensions at M12
mm · DIN 6796 · current edition 2009-08| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M12 | – | – |
| d1 | Inner diameter | 13 | – | – |
| d2 | Outer diameter | 29 | – | – |
| h | Free height | – | 3.43 | 3.95 |
| s | Material thickness | 3 | – | – |
- Approx. weight
- ≈ 12.43 kg per 1 000 pieces · Bare steel, before coating and packing.80.5 pieces per kg
