DIN 6796 M16 Conical Spring Washer
In stock in 4 material, grade and finish combinations.
Dimensions at M16
mm · DIN 6796 · current edition 2009-08| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M16 | – | – |
| d1 | Inner diameter | 17 | – | – |
| d2 | Outer diameter | 39 | – | – |
| h | Free height | – | 4.58 | 5.25 |
| s | Material thickness | 4 | – | – |
- Approx. weight
- ≈ 30.38 kg per 1 000 pieces · Bare steel, before coating and packing.32.9 pieces per kg
