ISO 2009 M10 x 16 Slotted Countersunk Head Screw
In stock in 4 material, grade and finish combinations.
Dimensions at M10 x 16
mm · ISO 2009 · 2011 edition| Dimension | Nominal | Min | Max | DIN 963 | |
|---|---|---|---|---|---|
| d | Thread size | M10 | – | – | M10 |
| P | Thread pitch | 1.5 | – | – | 1.5 |
| l | Length | 16 | – | – | 16 |
| dk | Theoretical head diameter | 18.3 | – | 20 | — |
| k | Head height | 5 | – | – | 5 |
| n | Slot width (nominal) | 2.5 | – | – | 2.5 |
| t | Slot depth | – | 2 | – | 2 |
| b | Thread length | 38 | – | – | — |
- DIN 963
- Values in bold differ from ISO 2009.
- Length incl. head
- 16 mm · 15.65–16.35 mm to ISO 2009 product grade A
- Approx. weight
- ≈ 11.60 kg per 1 000 pieces · Bare steel, before coating and packing.86.2 pieces per kg
Holes for this thread
ISO 273 · ISO 2306Clearance hole · fine10.5 mm
Clearance hole · medium11 mm
Clearance hole · coarse12 mm
Tap drill8.5 mm
