DIN 6796 M8 Conical Spring Washer
In stock in 4 material, grade and finish combinations.
Dimensions at M8
mm · DIN 6796 · current edition 2009-08| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M8 | – | – |
| d1 | Inner diameter | 8.4 | – | – |
| d2 | Outer diameter | 18 | – | – |
| h | Free height | – | 2.24 | 2.6 |
| s | Material thickness | 2 | – | – |
- Approx. weight
- ≈ 3.13 kg per 1 000 pieces · Bare steel, before coating and packing.320 pieces per kg
