DIN 508 M30 Nut for T-Slots
Made to order in 4 material, grade and finish combinations.
Dimensions at M30
mm · DIN 508 · 2002-06 · withdrawn| Dimension | Nominal | Min | Max | |
|---|---|---|---|---|
| d | Thread size | M30 | – | – |
| Thread pitch | 3.5 | – | – | |
| a | T-Slot width | 36 | – | – |
| e | Width across corners | – | 54 | – |
| f | Raised head height (ref) | 6 | – | – |
| h | Washer thickness | 44 | – | – |
| k | Head height | 22 | 21 | – |
| Approx. mass | 770 | – | – |
- Approx. weight
- ≈ 770.00 kg per 1 000 pieces · Bare steel, before coating and packing.1.3 pieces per kg
