ISO 4028 M20 x 60 Dog Point Socket Set Screw
In stock in 6 material, grade and finish combinations.
Dimensions at M20 x 60
mm · ISO 4028 · dimensions from 2003 · current edition 2026| Dimension | Nominal | Min | Max | DIN 915 | |
|---|---|---|---|---|---|
| d | Thread size | M20 | – | – | M20 |
| P | Thread pitch | 2.5 | – | – | 2.5 |
| l | Length | 60 | – | – | 60 |
| s | Hex socket size | 10 | – | – | 10 |
| t | Key engagement, short length | – | 8 | – | — |
| t | Key engagement, long length | – | 12 | – | — |
| dp | Point diameter | – | 14.57 | 15 | — |
| z | Point length, short type | – | 5 | 5.3 | — |
| z | Point length, long type | – | 10 | 10.36 | — |
| Short length limit | 25 | – | – | — |
- DIN 915
- Values in bold differ from ISO 4028.
- Length
- 60 mm · 59.4–60.6 mm to ISO 4028 product grade A
- Approx. weight
- ≈ 107.00 kg per 1 000 pieces · Bare steel, before coating and packing.9.3 pieces per kg
Holes for this thread
ISO 273 · ISO 2306Clearance hole · fine21 mm
Clearance hole · medium22 mm
Clearance hole · coarse24 mm
Tap drill17.5 mm
